useDraggable
Use the useDraggable
hook to make draggable elements that can dropped over droppable targets.
Usage
The useDraggable
hook requires an id
and accepts all the same options as the Draggable
class. Refer to the Input section below for more information.
API Reference
The useDraggable
hook is a thin wrapper around the Draggable class that makes it easier to create draggable elements in React. It therefore accepts all of the same input arguments.
Input
The useDraggable
hook accepts the following arguments:
The identifier of the draggable element. Should be unique within the same drag and drop context provider.
Optionally supply a type to only allow this draggable element to be dropped over droppable targets that accept this type
.
If you already have a reference to the element, you can pass it to the element
option instead of using the ref
that is returned by the useDraggable
hook to connect the draggable source element.
If you already have a reference to the drag handle element, you can pass it to the handle
option instead of using the handleRef
that is returned by the useDraggable
hook to connect the drag handle element.
Set to true
to prevent the draggable element from being draggable.
The type of feedback that should be displayed when the element is being dragged.
An array of modifiers that can be used to modify or restrict the behavior of the draggable element.
An array of sensors that can be bound to the draggable element to detect drag interactions.
The data argument is for advanced use-cases where you may need access to additional data about the draggable element in event handlers, modifiers, sensors or custom plugins.
useDraggable
hook element is unmounted.Output
The useDraggable
hook returns an object containing the following properties:
A ref callback function that can be attached to the element that you want to make draggable.
A ref callback function that can be attached to an element to create a drag handle.
A boolean value that indicates whether the element is currently being dragged.
The draggable instance that is created by the useDraggable
hook.
Guides
Specifying a drag handle
To specify a drag handle, provide a reference to an element and pass it as the handle
argument to the useDraggable
hook. Alternatively, you can consume the handleRef
ref callback to connect the drag handle element.
When you connect a drag handle element, only the element that is connected to the handleRef
will initiate the drag operation.
Restricting dragging using modifiers
Use modifiers to modify or restrict the behavior of draggable elements.
Modifiers let you dynamically modify the movement coordinates that are detected by sensors. They can be used for a wide range of use cases, for example:
- Restricting motion to a single axis
- Restricting motion to the draggable node container’s bounding rectangle
- Restricting motion to the draggable node’s scroll container bounding rectangle
- Applying resistance or clamping the motion
Modifiers can be applied globally on the <DragDropProvider> component or locally on individual draggable elements.
Here is an example of how to restrict dragging to the horizontal axis:
And here is an example of how to restrict dragging to the container element of the draggable:
